PDL600 Switches

PDL Switch 600 Series - Assembled - Vertical - 1-gang - 250 V - 32 A / 20 AX

Part of the: PDL 600 Series Range

Switch assembly. 600 series cover plate, grid and switch mechanism are included. Suitable for 1-gang vertical installations. Assembled with plate. PDL 600. Colour: White Rated current: 32A / 20AX. Operating voltage 250V a.c. 50Hz Note: Requires installation by an appropriately licenced electrician.

Features:

• Vertical Range Switch 32A
• Plate: 118mm H x 74mm W
• Mounting centres: 84mm
• Suits cat 89 mounting block, Cat 144 flush box, Cat 145V,148V or 146V mounting bracket
• Suits Cat 680M# coloured cover plate
• Complies with Standards: AS3100 and AS3133

Ratings SP: 230V - 240V a.c.,  50Hz,  32A resistive,  25AX inductive,  M180. 3mm contact gap.  Terminals accommodate: 2x6mm2 cables each

Ratings DP: 400v-415v A.C., 50hZ, 32a resistive, 32AX inductive.
Terminals accommodate: 4x2.5mm2 cables each or 3x4mm2 cables each.
