PDL600 Switches

PDL Switch 600 Series - Assembled - Vertical - 2-gang - Single-pole - 250 V - 16 A / 16 AX – White

Part of the: PDL 600 Series Range

Switch assembly. Single-pole switch. Suitable for 2-gang vertical installations. Assembled with plate. PDL 600. Colour: White Rated current: 16A / 16AX. Operating voltage 250V a.c. 50Hz Note: Requires installation by an appropriately licenced electrician.

Features:

• 250V a.c, 50Hz, 20A Resistive, 20AX Highly Inductive, 16AX Flourescent to EN 60669-1, M60, Motor Rating.
• Terminals accommodate: 4 x 1.5mm2 cables each or 2 x 2.5mm2 cables each.
• Plate: 118mm x 74mm
• Mounting Centres: 84mm
• Vertical or Horizontal Mounting.
• Suits PDL89 Mounting Block, PDL144 Flush Box and PDL145V, PDL148V, PDL148H, PDL146V or PDL146H Mounting Bracket.
• Switches comply with Standards: AS3100, AS3133, BS3676 and AS1939.
• Switches meet the requirements for installation in Zone 1 as per AS/NZS 3000:2000, Sections 7.1, 7.2 and 7.6 and NZS 3000:1997, Sections 702.9.2 and 702.9.

Note:  Switches, Grid Plates and Modules come in white or black.  To have a different coloured cover plate, eg polished brass, stainless steel or brushed bronze then you must ALSO purchase a cover plate to match the unit.
